Company ASTAS with its headquarter in Istanbul and further 12 branch offices in Turkey and abroad is a specialist in sewing technology and an acknowledged partner for the leading garment industry and trade brands for more than 40 years. Our vision is to serve maximum support for the worldwide competitiveness of the garment and apparel sector, to supply the most innovative solutions to increasing workshops and thus help the sector heading for high value-added items. In addition, adapting the latest technology equipment to the existing machinery park, in order to provide the best service to achieve the energy economization and time management and high quality and highest efficiency.
ASTAS self-made workstations offer intelligent solutions for the garment industry with automatic sewing machines and sewing stations simplify sewing processes and thus also increase productivity. We supply our workstations, which are custom-made, to the textile and garment industry, to the automotive and mattress industry, to companies with technical textiles.
Fully Automatic Fabric Spreading Machine – SRM 255 XXL SERIES
• Denim/Jeans – assembled for spreading the large type weaving fabric
• Preferable language; Turkish or English
• Remote connection (option)
• Via intensive sensor, the ability to spread the beginning of the fabric in each ply in some line automatic (gain fabric)
• Ability to interfere with the software and spread at fully automatic mode
• Auto-Stop feature when the roll runs out or pre recorded number of folds is achieved
• Ability to unroll or rewind (for Roll Fed Fabrics)
• Ability to enter different speed choices, in order to save time during idle turns
• One way or zig-zag spreading features (zig-zag is optional)
• Spreader system which ascends automatically, in accordance with spreading height
• Backwards opening cradle and loading extension, enabling easy fabric loading
• Maximum operation comfort, by means of its operator carrier platform
• True-sense safe operation, ensured by privileged safety sensors
• User-friendly Touch Screen pane
AST-7923/ERDO-KR/M-PLC-2/SM-BDN
Top Covering Type, Cover Seam Bottom Hemming Automat with Step Motor Controlled Special Automatic Size Adjustment Device with Sensor
• Hemming adjustment attachment system between 17-30 mm.
• Able to work 40-80cm tubular shirt bottom hem
• Stitching starts and ends at the side seam
• Stitch alignment feature thanks to sensor-controlled system
• Thanks to the size tolerance system, the machine can adapt itself for measurement differences up to 1 cm for the same sizes
• Step motor controlled size adjustment feature – SM-BDN
• Hemming correction feature by means of roller system at the start of seam
• One operator can run 2 machines
• Excellent 3 needle Top Covering Type or 2 needle cover seam stitch quality
• LCD touchscreen control unit
• Daily piece counter
• Thread breaking sensor
• Automatic stacker unit
• Up to %40 energy-saving thanks to direct drive Efka servo motor technology
• Capacity 2.400-3.000 pcs/ 8 hours
